K3PGP Experimenter's Corner

Lunar Prospector


Lunar Prospector to impact the lunar surface at 9:51 GMT 07/31/99 !!!

The Downlink

Prospector Heard ! Transmitter Specs

Actual Off Air Sound Recordings of Lunar Prospector!


The Uplink !

VE4MA hears the Uplink to Lunar Prospector via EME !


Tracking and Data

Real time Tracking and Data

Lunar Prospector Status Reports

Launch Report !

According to NASA, the Lunar Prospector is going to be launched at 23:31 UTC, 5 Jan 1998 (8:31pm EST) from Spaceport Florida's new Launch Complex 46 in Cape Canaveral.

The mission does not carry a camera, but it is expected to settle the issue of water trapped in ice deposits under the moon's surface. The frequencies for the probe are going to be the following:

2273.000 MHz downlink / 2093.0541 MHz uplink

Although I don't know the bandwidth of the expected emissions, I would expect there will be no problem hearing the probe downlink at 2273.000 Mhz. However, what might be most interesting is to look for the UPLINK via EME at 2093.0541 +- doppler !!!

This should be an excellent test for the sensitivity of your Rx equipment. I would appreciate any reception reports.


The link(s) below should be active during the current lunar probe mission !

http://lunarprospector.arc.nasa.gov

http://lunar.arc.nasa.gov/

http://www.nitehawk.com/rasmit/lunar_prosp.html (W6/PA0ZN)

http://spmgs1.cfn.ist.utl.pt/~cupido (CT1DMK)

http://www.abcnews.com/sections/scitech/moon0102/index.html

Note: The above link may change daily! Try shortening it to:

http://www.abcnews.com/sections/scitech/

And from time to time some interesting things show up at the CNN site!

http://www.cnn.com
